AXE-1825/H16MF

Cable Female 3P, Black body, silver contacts, dis-assembled,

3 pole female cable connector with black metal housing and silver contacts. The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief. Features & Benefits •Unique cage design of female contact for low contact resistance and high integrity •Female contact incorporates a solder barrier to prevent solder running into the contact mating area •Female connector with improved solid metal latch which is larger and easier to handle •Additional ground spring contacts for better shell ground continuity •Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster •Boot with polyurethane gland gives high protection to cable bending stresses •Colored rings and boots available for coding or identification •Sleek and ergonomic design - valuable and handy •Rugged zinc diecast shell, longlasting and dependable •Internal thread on shell is well protected against any damage •Branded with unique hologram - guarantees genuine and authentic Neutrik product

Male cable CEE 16A/230V/3P BLACK

Alle Bals stekkers en koppelstekkers zijn impact-bestendig en stabiel bij extreem hoge temperaturen. Ze zijn ook duurzaam en bevatten geen PVC, cadmium of halogeen. Bals onderscheidt zich nog door gebruik te maken van nieuwe ontwikkelingen om de installatie veiliger en gemakkelijk te maken.

Zo maakt de Duitse fabrikant gebruik van Kontex contact. Hierbij is er een gedefinieerd contact dankzij veermechanisme in roestvrij staal.

Verder gebruiken ze ook een schroefloze boxveerklem aansluiting voor het bevestigen van kabels. Dit Quick-Connect systeem zorgt ervoor dat de kabel betrouwbaar, permanent en met een constante klemdruk vast zit. Het is onderhoudsvrij, tril- en schokbestendig. Daarenboven kunnen meerdere kabeldiameters probleemloos worden aangesloten en bespaart dit systeem tot 75% installatietijd.

Tenslotte is Bals ook fier op de door hun uitgevonden Multi-Grip techniek. Dit is een uniek en optimaal kabelsparend trekontlastingssysteem voorzien van 18 flexibele lamellen met onverliesbare gummidichting. Overigens kunnen verschillende kabeldiameters worden bevestigd.

Microphone Cable Stage 22 Highflex; 2 x 0,22 mm²; PVC Ø 6,40 mm; black

Technical Data: - Properties: Analog - Properties: OFC oxygen free copper - Application area: Stage / live - Application area: Mobile outdoor / indoor - Application area: Installation - Application: Microphone Cable - Colour: black - Colour detailed: black - Signal transmission: symmetrical - Jacket material: PVC - Jacket Ø: 6,4 mm - Number of Channels (audio): 1 - Inner conductor (audio): 2 - Inner conductor (audio): 0,22 mm² - Inner conductor Ø (audio): 0,53 mm - AWG (audio): 24 - Shielding: Copper spiral shielding with 0.10 mm indiv. strands - Copper strands (audio): 28 - Copper strand Ø (audio): 0,10 mm - Weight per 1 m: 44 g - UV-resistant: yes - Fire load per m: 0,22 kWh - Style variant: round - Shielding factor: 99 % - Packing: 100 m spool - Packing: 500 m spool - Temperature min.: -20 °C - Temperature max.: 70 °C - Width: 6,4 mm - Height: 6,4 mm - Capac. cond./cond. per 1 m (audio): 68 pF - Capac. cond./shield. per 1 m (audio): 130 pF - Impedance: 100 Ω - Insulation resist. per 1 km: 1 GΩ - Insulation resist. per 1 km (audio): 1 GΩ - Conductor resistance per 1 km: 87 Ω - Shield. resistance per 1 km: 30 Ω

AUDIO MULTI 4 PAIRS

The SYNTAX® AUDIO MULTIPAIR cables are developed for high-standard professional applications in the rigorous environments of the audio & video installations, studio recording and musical entertainment, everywhere excellent electrical and mechanical properties are required. The pairs are twisted and jacketed; the external PVC jacket of each pair is individually numbered. All jacketed pairs are inside an outer PVC sheath whose internal talc dusted lined ridges allow the cores to slide against one other, yet maintain them properly clustered even under heavy usage and continuous rewinding. This solves the problems of twisting and knotting of the cores while keeping the right cable flexibility. The XLPE conductor insulation is particularly resistant to high temperatures, so as to avoid warping or shrinkage when soldering. The aluminium/polyester foil shield provides a 100% screen and the drain wire inside allows fast installation. All the conductors are made of High Purity Oxigen Free Copper. The extra-flexible PVC external jacket is anti-trampling and anti-scratch for usage at either extremely low or high temperatures, ranging from -30°C up to +70°C.
