KAC-KH-1.5/12(1000pc)

Speaker Cable Elephant SPM415; 4 x 1,50 mm²; PVC Ø 8,60 mm; black

Technical Data: - Properties: Analog - Properties: OFC oxygen free copper - Application area: ELA 100 V - Application area: Studio / Broadcast - Application area: Stage / live - Application area: Mobile outdoor / indoor - Application area: Installation - Application: Speaker Cable - Colour: black - Colour detailed: black - Jacket material: PVC - Jacket Ø: 8,6 mm - Number of Channels (audio): 1 - Inner conductor (audio): 4 - Inner conductor (audio): 1,5 mm² - Inner conductor Ø (audio): 1,38 mm - AWG (audio): 15 - Copper strands (audio): 84 - Copper strand Ø (audio): 0,15 mm - Conductor insulation Ø: 2,6 mm - Weight per 1 m: 120 g - UV-resistant: yes - Fire load per m: 0,58 kWh - Style variant: round - Packing: bulk stock - Temperature min.: -25 °C - Temperature max.: 70 °C - Width: 8,6 mm - Height: 8,6 mm - Insulation resist. per 1 km: 0,005 GΩ - Insulation resist. per 1 km (audio): 0,005 GΩ - Conductor resistance per 1 km: 12,6 Ω - Test voltage: 2000 V

Cable Speakon [6-12mm] - 4P , Female

4 pole speakON cable connector, screw terminal assembly, chuck type strain relief for cable diameters 6 to 12 mm

speakON connectors are the industry-standard for loudspeaker connections. This product series offers extremely reliable and robust cable connectors with a proven twist lock system. speakON cable connectors feature solid contacts with screw-type terminals including a stranded wire protection

Features & Benefits

Cable Speakon, 8P, Female, Black

8 pole cable connector, latch lock, chuck type strain relief for cables 8 - 20 mm diameter, 30 A continuous per contact The industry-standard for loudspeaker connections offer extremely reliable and robust cable connectors with a reliable locking system. They feature solid contacts with screw-type terminals including a stranded wire protection which offer also solder termination. Features & Benefits •Current rating 30 A rms continuous •Reliable and robust, easy and fast to assemble •Contacts are touch proof and meet all safety requirements (IEC, UL, CSA) •Accurate and dependable twist lock latching system "Quick Lock" •High impact material for insert and housing, long-lasting and dependable •Chuck type strain relief system for secure clamping of cable

Starfix isolated 6mm²/12mm
