Insert Male 16E with screw contacts
Artikelnummer 09 33 016 2601
Beschrijving Han E MALE INSERT SCREW
Type sheet PDFPDF
Identification
Category
Inserts
Series
Han E®
Termination method
Screw termination
Version
Gender
Male
Size
16 B
With wire protection
Yes
Number of contacts
16
PE contact
Yes
Technical characteristics
Conductor cross-section
0.75 ... 2.5 mm²
Electrical data acc. to IEC 61984
16 A 500 V 6 kV 3
Rated current
16 A
Rated voltage
500 V
Rated impulse voltage
6 kV
Pollution degree
3
Rated voltage acc. to UL
600 V
Rated voltage acc. to CSA
600 V
Contact resistance
? 1 m?
Limiting temperature
-40 ... +125 °C
Tightening torque
0.5 Nm
Mating cycles
? 500
Material properties
Material (insert)
Polycarbonate
Colour (insert)
RAL 7032 (pebble grey)
Net weight
85.8 g
RoHS
compliant with exemption
Specifications and approvals
Specifications
IEC 61984
EN 60664-1
Approvals
CSA-C22.2 No. 182.3 PVVA8.E318390
UL 1977 ECBT2.E235076
UL 2237 PVVA2.E318390
GL
Yes
Declaration of Conformity
