DIS-DBXL

Procable softflex 18x2,5mm² black

Type: MULTIFLEX-SOFT 18 x 2,5 mm2, black
Nominal voltage: 300/500 V
Conductor: finely wired acc. to VDE 0295
Copper construction: 50 x 0,25 mm
Core insulation: PVC-mixture – shorehardness 90+/- 3
Laying of cores: Centre: PVC filler, 1. lay = 6 cores,
2. lay = 12 cores
Core colours: 17 x black with white numbers+1 green-yellow
Jacket: Soft PVC-mixture, black (RAL 9005)
Shorehardness 65 +/- 3
Presure extrusion, with talc, printing: optional
Outside diameter: approx. 19,4 ± 0,40 mm
Test voltage > 3 kV – at 50 Hz eff. for 1 minute
Insulation resistance: min. 20 MOhm x km at 20°C
Conductor resistance: max. 7,98 Ohm/km at 20°C
Operating voltage: max. 500 V
Temperature rating: static: -30 up to +80 °C
operating: - 5 up to +70 °C
This cable is flame retardant acc. DIN VDE 0482 part 265-2-1



Male cable CEE 32A/380V/5P

Order number 2148 EAN/pcs 4024941021487 Product Group QUICK-CONNECT plug with MULTI-GRIP cable gland Amperage 32A Poles 5p (3p+N+PE) Earth 'Clock' Position 6 h Voltage 200/346 up to 240/415V Frequency 50 and 60Hz Protection IP44 Color code red RAL 3000 Connection Design screwless spring-clamp technology as cage clamp Max. conductor 6,0 mm²

Declaration of Conformity

Female cable CEE 63A/380V/5P

Order number 3124 EAN/pcs 4024941031240 Product Group TE connector MULTI-GRIP Cable gland Amperage 63A Poles 5p (3p+N+PE) Earth 'Clock' Position 6 h Voltage 200/346 up to 240/415V Frequency 50 and 60Hz Protection IP67 Color code red RAL 3000 Connection Design Screw Terminal as box terminal with Kontex-contact Max. conductor 16,0 mm²

Declaration of Conformity

Power Distri 360*500*420 32/5 to 1*32/5 & 12*abl

V45.36.0544 Polyethyleen stapelbare verdeelkast type V45.36, horizontaal gebouwd (b x h x d = 500x360x420 mm)

o Dubbelgeïsoleerd klasse II
o Slagvast
o 4 handgrepen geïntegreerd
o 8 beschermings- en stapelhoeken
o Wcd’s en beveiligingen verzonken (beschermd) gemonteerd
o Bouwvorm kan zowel horizotaal als verticaal worden geleverd (keuze)
o Stapelbaar op de overige kasten in de nieuwe generatie V45
o Stapelmaat: 420x500
Earth connection 1x Aardebout M8 groen geel met afneembare vleugelmoer?
Fase indication 3x Signaallamp Neon 230V rood incl. chroomrand en o-ring IP44
Input 1x Apparatenstekker recht CEE 400V 32A 5p 6h IP44 rood
Loop 1x Inbouwdoos recht CEE 400V 32A 5p 6h IP44 rood
Output 12x Inbouwdoos Schuko 230V 16A 2p + penaarde IP44 blauw kleine flens
security 6x Aardlekautomaat type PKN6 16A 1polig + Nul 30mA C-kar. 6kA

Declaration of Conformity
