NEU-NF2D-B-9

Panel 3 pole Male, Black housing, silver contacts, D-size

3 pole male receptacle, solder cups, black metal housing, silver contacts The DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding. It is the ideal match for mating with Neutrik's EMC XLR cable connector. Features & Benefits •All metal housing offers best overall RF protection and electromagnetic shielding •Duplex ground contact for excellent contact integrity between chassis and cable connector •Male connector's retention bar replaces plastic design with all metal version improving pull-out force •Larger solder contacts for easier termination •Optional connection to easily join pin1 to chassis ground •D-style housing provides installation compatibility with industry standard D mounting dimensions

Panel 3 pole Female, Black housing, silver contacts, D-size

Dummy-plate to cover D-shape cutouts

Dummy-plate to cover D-shape cutouts

Isolated BNC chassis connectors, feedthrough in black D-shape housing

Isolated BNC chassis connectors, feedthrough in black D-shape housing Neutrik's BNC chassis connectors offer a true 75 ? design for serial and digital (HD) signals. The machined brass connector body provides an extremely rugged and non-abrasive connection over long term use and is in addition recessed and therefore well protected in a D-shape housing (audio industry standard). Features & Benefits •Gold plated cage type center contact •True 75 ? design meets the stringent HD requirements •Isolated panel mount (solves potential grounding problems and prevents common-mode influence with other connections conducted over the same panel ground potential) •Standard D-shape housing - provides flush mounting and protection from demage •Color coding possible New cage type contact •Closed contact design - extremely robust •Gold plated cage type clip - best possible shielding and lowest contact resistance
