PCE-CE1040-0S

Female chassis SCHUKO 16A/230V/2+A BE-FR - SCREW - BLUE

Easy-Lock 10E/16E/24E Grey

Artikelnummer 09 00 000 5221 Beschrijving LOCKING LEVER PLASTIC Type sheet PDFPDF Identification Category Accessories Series of hoods/housings Han® B Type of accessory Locking levers Locking type Double locking lever Han-Easy Lock® Yes Version Size 10/16/24 B Technical characteristics Flammability acc. to UL 94 (locking levers) V-0 Material properties Material (accessories) Stainless steel Polycarbonate Colour (accessories) RAL 7037 (dust grey) Net weight 18.97 g RoHS compliant

Declaration of Conformity

Insert Male 16E with screw contacts

Artikelnummer 09 33 016 2601 Beschrijving Han E MALE INSERT SCREW Type sheet PDFPDF Identification Category Inserts Series Han E® Termination method Screw termination Version Gender Male Size 16 B With wire protection Yes Number of contacts 16 PE contact Yes Technical characteristics Conductor cross-section 0.75 ... 2.5 mm² Electrical data acc. to IEC 61984 16 A 500 V 6 kV 3 Rated current 16 A Rated voltage 500 V Rated impulse voltage 6 kV Pollution degree 3 Rated voltage acc. to UL 600 V Rated voltage acc. to CSA 600 V Contact resistance ? 1 m? Limiting temperature -40 ... +125 °C Tightening torque 0.5 Nm Mating cycles ? 500 Material properties Material (insert) Polycarbonate Colour (insert) RAL 7032 (pebble grey) Net weight 85.8 g RoHS compliant with exemption Specifications and approvals Specifications IEC 61984 EN 60664-1 Approvals CSA-C22.2 No. 182.3 PVVA8.E318390 UL 1977 ECBT2.E235076 UL 2237 PVVA2.E318390 GL Yes

Declaration of Conformity
