PCE-CE105-0S

Panel 3 pole Female, Black housing, silver contacts, D-size

Panel 3 pole Male, Black housing, silver contacts, D-size

3 pole male receptacle, solder cups, black metal housing, silver contacts The DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding. It is the ideal match for mating with Neutrik's EMC XLR cable connector. Features & Benefits •All metal housing offers best overall RF protection and electromagnetic shielding •Duplex ground contact for excellent contact integrity between chassis and cable connector •Male connector's retention bar replaces plastic design with all metal version improving pull-out force •Larger solder contacts for easier termination •Optional connection to easily join pin1 to chassis ground •D-style housing provides installation compatibility with industry standard D mounting dimensions

Panel speakON 4 pole chassis, black D-size, countersunk screw holes, 3/16" flat tabs

This connector is fully compliant to the device standard IEC 62368-1, due to its component certification according to IEC 61984.

4 pole chassis connector, black D-size flange, countersunk thru holes, 3/16" flat tabs.

The speakON panel mount connectors are the standard chassis connectors for loudspeaker / amplifier interconnections. They feature a unique metal locking system, making contact only once fully locked. The speakON receptacles are robust, versatile and easy to terminate.



Features & Benefits

Panel CAT5e feedthrough, D-shape, Black housing

RJ45 feedthrough receptacle, black D-shape metal flange with the latch lock, mounting screws included The etherCON Series is a ruggedized and lockable RJ45 connector system, optimized for pro audio, video and lightning network applications. The chassis connectors are shaped to fit into standardized panels out of the entertainment industry. The D-Series offers the most rugged design of the etherCON series and is perfectly suitable for panel mount and the installer market. Attention! Does not intermate with CAT6 cable connector NE8MC6-MO and NKE6S* cables. Features & Benefits •Accommodates NE8MC* or any standard RJ45 plug •Approved latch lock system •Mountable from the front or rear of the panel •Complies with Cat 5e according to TIA / EIA 568B and ISO / IEC 11801 standard
