PET-25/06240010010

Flexible Power Cable H-07 3G1,5mm²/m - Outside diameter: 11,9mm

Locations where a low level of emission of smoke and corrosive gases are

required in case of fire or burning; use in industrial and agricultural

workshops, building sites, for heavy duty applications and supplying

industrial and agricultural machines and appliances where cables are

subject to medium mechanical stresses (e.g. heating plates, inspection

lamps, electric tools such as drills, circular saws, and domestic electric tools)

use in dry, humid or moist rooms; fixed installations e.g. on rough-cast in

temporary buildings and huts for accommodation purposes .Supply of

electricity and communications in buildings and other civil engineering

works with the objective of limiting the generation and spread of fire and

smoke.In addition the cables are especially suitable for use as connection to

machine tools

Cable Female PowerCON - [6-12mm] - Grey, 20A

Locking AC mains cable connector, keyed and color coded (grey) for power-out, screw terminal assembly, for cable diameters 6 - 12 mm.

The powerCON FXXA/FXXB is a single phase (3 conductor) lockable power connector with Circuit Breaking Capability when mated with powerCON XX Series receptacles.

It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed to guarantee a safe power connection.

GREY - Male Panel PowerCON - 20A power-out - 3/16'' flat tab terminals

Chassis connector, power-out, 3/16'' flat tab terminals, grey The powerCON is a locking 3 conductor equipment AC connector with contacts for line, neutral and pre-mating ground contact. It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed in order to guarantee a safe power connection. Attention: The powerCON is a connector without breaking capacity, i.e. the powerCON should not be connected or disconnected under load or live! Features & Benefits •Locking 20 A / 250 V ac appliance coupler •3 contacts for line, neutral and premating safety ground •Power-in (blue) and power-out (grey) versions with different keying to avoid the possibility of intermating •Fast and easy twist lock latching system •Extremely robust and reliable •Ergonomic design •User friendly latch design for easy handling •UL, cUL recognized components VDE certified •Branded with unique hologram - guarantees genuine and authentic Neutrik product

Cable Female 3P, Nickel body, silver contacts

3 pole female cable connector with Nickel housing and silver contacts. The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief. Features & Benefits Unique cage design of female contact for low contact resistance and high integrity Female contact incorporates a solder barrier to prevent solder running into the contact mating area Female connector with improved solid metal latch which is larger and easier to handle Additional ground spring contacts for better shell ground continuity Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster Boot with polyurethane gland gives high protection to cable bending stresses Colored rings and boots available for coding or identification Sleek and ergonomic design - valuable and handy Rugged zinc diecast shell, longlasting and dependable Internal thread on shell is well protected against any damage Branded with unique hologram - guarantees genuine and authentic Neutrik product
