Adapter Powercon M/F - Powercon TRUE1 F

• T-split box met Seetronic Powercon compatible ingang/uitgang en Seetronic Powercon TRUE 1 compatible uitgang.
• Ideale probleemoplosser om een armatuur met Powercon TRUE 1 (of compatibel) aan te sluiten in een keten met conventionele Powercon (of compatibele) connectoren.
• Voorzien van Seetronic Powercon compatibele connectoren.
• Afmetingen: 3,7 x 9,3 cm
• Lengte van de kabel: 80 cm

Adapter Powercon TRUE1 compatible M/F - Powercon F

• T-split box with Seetronic Powercon TRUE1 compatible Input/output and Seetronic Powercon compatible output.
• Ideal problem solver to connect a fixture with conventional Powercon (or compatible) in a chain with Powercon TRUE1 (or compatible) connectors.
• Equipped with Seetronic Powercon compatible connectors.
• Length of cable: 80 cm

Spider 419 Male to 6 TRUE1 Female

Standard wiring 1+2+13, 3+4+14, 5+6+15, 7+8+16, 9+10+17, 11+12+18

Spider 419 Female to 6 TRUE1 Male

Standard wiring 1+2+13, 3+4+14, 5+6+15, 7+8+16, 9+10+17, 11+12+18

Axept Break-out box Harting 16p - 8x True1 - Harting 16p

Standard wiring 1+9, 2+10, 3+11, 4+12, 5+13, 6+14, 7+18, 8+19
Protect Cover on output side

VULCA TAPE (WHITE, 19mm, 10M) - Piece

Self-vulcanizing insulation tape.
Made from high-quality rubber that fuses to itself after application, creating a seamless, waterproof, and weather-resistant bond.
Offers excellent electrical insulation, high aging resistance, and remains flexible under extreme temperatures.
Free from adhesives — the tape bonds through vulcanization upon wrapping.
Supplied with an easy-to-remove protective liner.

CAT6/ Neutrik black connector/ Belden 1302E/Drum/ DOOR

Cable : Belden 1302E Connector : Neutrik Ethercon CAT6 Accesories : Transparent Heat Shrink x 2 Drum : Schill GT310MFK

Sixty82 - Leg to leg 2 way

WHY STAGE82:

- Frame design facilitates much easier handling and pick up by hand
- Scaffolding event beam compatible
- Double painted plywood topping
- Easy repair as completely bolted

Technical Specifications:
- 750kg/m2
- Lateral loading 10%
- Plywood 15mm
- 36 kg (2x1)

Titanex H-07RN-F 3G2,5mm²/m - Outside diameter: 14mm

The TITANEX® flexible rubber cable range offers exceptional performances and is designed to release you from all your constraints. Robust yet flexible, TITANEX® is easy to use and withstands the toughest of conditions, such as hard-wearing situations, extreme temperatures and most chemicals. For more than 50 years the TITANEX® cable range properties have been recognized as the best choice for all mobile and fixed installations in industrial environments such as construction sites, cranes, machines tools, factories, generators etc.

TITANEX® is also suitable for public environments and temporary events such as festivals or sports competitions, where the cable is often laid directly on the ground with no protection.



The cable may be rated 0,6/1 kV where the installation has built-in protection and for motors in lifting appliances - machine tools - etc.

When pick up at Willebroek, reels of 500 meters are possible, when you select transport, only 100 meter lengths will be sended.

Cloth Tape Nichiban 1200 50 MM X 50 M Black BOX/18pc

• Tapes with strong adhesive power, perfect for sealing heavy packages.
• The tape can be easily rewound, helping you work efficiently.
• You can tear the tape easily with your fingers.
• The tapes come in twelve standard colours.
• Useful for coding and identifying different objects.

Nichiban 19mm - 48PC/box

Nichiban 25mm - 36pc/box

Nichiban 38mm - 24pc/box

Nichiban 50mm - 18pc/box

Nichiban 100mm - 6pc/box



Display Stand

Dimensions:

Base incl tube holder:
60x48x18cm

Base height:
3cm

Pole:
200cm

NO TRANSPORT POSSIBLE

Power Distri 360x500x420 63/5 to 1x63/5 & 2x32/5 & 6xABL (BELGIUM/FRANCE)

V45.36.0605 Polyethyleen stapelbare verdeelkast type V45.36, horizontaal gebouwd (b x h x d = 500x360x420 mm)

o Dubbelgeïsoleerd klasse II
o Slagvast
o 4 handgrepen geïntegreerd
o 8 beschermings- en stapelhoeken
o Wcd’s en beveiligingen verzonken (beschermd) gemonteerd
o Bouwvorm kan zowel horizotaal als verticaal worden geleverd (keuze)
o Stapelbaar op de overige kasten in de nieuwe generatie V45
o Stapelmaat: 420x500
Fase indication 3x Signaallamp Neon 230V rood incl. chroomrand en o-ring IP44
Earth connection 1x Aardebout M8 groen geel met afneembare vleugelmoer
Input 1x Apparatenstekker recht CEE 400V 63A 5p 6h IP67 rood
Loop 1x Inbouwdoos recht CEE 400V 63A 5p 6h IP67 rood
Output 2x Inbouwdoos recht CEE 400V 32A 5p 6h IP44 rood
Output 6x Inbouwdoos Schuko 230V 16A 2p + penaarde IP44 blauw kleine flens
security 1x Aardlekschakelaar type PFIM 63A 4polig 30mA
security 2x Installatie automaat type PLS6 32A 3polig + Nul C-kar. 6kA
security 1x Aardlekschakelaar type PFIM 40A 4polig 30mA
security 3x Inst. Automaat type PLN6 16A 1polig + Nul C-kar. 6kA

Declaration of Conformity

Power cable Titanex 3G2,5mm HO7RNF 0,5m/ Keraf connector

BE/FR standard

Female cable rubber

Volrubber koppelcontactstop 16A, 250V~ 2 polig met penaarde
(conform NBN C 61-112-1).

kleur : zwart
gewicht : 150 g

Eigenschappen:

• slijtvaste, olie- en zuurbestendige massief rubber mantel
• ontwikkeld voor zwaar industrieel gebruik
• zeer drukbestendig, vormvast rubber binnenwerk
• montagevriendelijk door wegklapbare trekontlasting
• vernikkelde contacten
• schroeven met kombi-kop
• reeds geopende contacten
• IP44 stof- en spatwaterdichte kabelinvoer
• geschikt voor neopreenkabel van 3 x 2,5 mm²

Black flexible 18*2,5mm/ Harting16E/Black hood straight/ 100m

Cable : Axept Procable 18*2.5mm² Connector : Harting Han16E M+F / Black hood Top entry Accesories : Transparent Heat Shrink x 2

SCHUKO PAC 2,5mm² in FLIGHT CASE / 10x 3m / 10x 5m / 10x 10m / 5x 20m / 15x Power Strip

Standard is for France/Belgium !
(for Germany/Netherlands please put comment in shopping cart, same price)

Delivery time: 1week

Display Bracket size: Medium + Fixation buttons M6/M8

INCLUDING FIXATION ACCESSOIRIES 4xM8 & 4xM6

Wall mount
Pole mount (Display Stand)
Truss mount 40/30 square/triangle

VESA 200 x 200
VESA 300 x 200
VESA 300 x 300
VESA 400 x 200
VESA 400 x 300
VESA 400 x 400

We recommend a maximum screen size of 65 inches for this bracket
For biger sizes please check our MWS-DBL and MWS-DBXL

Outer size: 510x510mm

Male cable rubber

Volrubber contactstop 16A, 250V~ 2 polig met bus- en randaarde
(conform NEN 1020 en NBN C 61-112-1).

kleur : zwart
gewicht : 120 g

Eigenschappen:

• slijtvaste, olie- en zuurbestendige massief rubber mantel
• ontwikkeld voor zwaar industrieel gebruik
• zeer drukbestendig, vormvast rubber binnenwerk
• montagevriendelijk door wegklapbare trekontlasting
• vernikkelde contacten
• schroeven met kombi-kop
• reeds geopende contacten
• IP44 stof- en spatwaterdichte kabelinvoer
• geschikt voor neopreenkabel van 3 x 2,5 mm²

Prikcable incl E27 - Socket/50 CENTIMETERS
